MB-Ruler Pro Help |
![]() ![]() |
|
|
Track mouse | the measured lines are always drawn |
Attach to window | when the measure instrument is moved, the window below will be detected and the instrument attached to this window. If this window is moved in a further operation, the measure instrument is moved synchron to this window. This mode is active, as long as the menu item Attach to window is checkd and the window is visible. If you minimize this window or close the attached application, the mode is deactivated, too. |
Modify - Set to origin state | the measure instrument is moved to a defined start position |
Modify - Rotate 180° | the measure instrument is rotated by 180° |
Modify - Rotate 90° clockwise | the measure instrument is rotated by 90° clockwise |
Modify - Rotate 90° anticlockwise | the measure instrument is rotated by 90° anticlockwise |
<Ctrl><Alt><C> | copy the measured values to the clipboard |
<Ctrl><Alt><cursor left> | move the measure instrument one pixel to the left |
<Ctrl><Alt><cursor right> | move the measure instrument one pixel to the right |
<Ctrl><Alt><cursor up> | move the measure instrument one pixel up |
<Ctrl><Alt><cursor down> | move the measure instrument one pixel down |
Transfer of the measured values
ValueID | Format of the return value |
1 | distance in x1 direction * 10 |
2 | distance in x2 direction * 10 |
ValueID | Format of the return value |
1 | LoWord: x coordinate of the origin HiWord: y coordinate of the origin/TD> |
2 | rotation angle of the x1 axis * 10 |
3 | rotation angle of the x2 axis * 10 |
4 | LoWord: x coordinate of the info field HiWord: y coordinate of the info field |
